Smartphone App Alerts Drivers Exceeding Speed Limits on Curves

Researchers have developed a proof-of-concept curve speed warning system for use with mobile phones, a technology they hope car manufacturers might adopt for in-vehicle systems. The proof-of-concept system uses data from local road agencies on curve locations, speed limits and signage with geofencing to trigger cloud-based data alerts to road users driving faster than recommended speeds for curves.

What Was the Need?

Over one-quarter of fatal highway crashes occur at horizontal curves. In Minnesota, these areas are a contributing secondary factor in 49 percent of fatal crashes. Each year, accidents on two-lane, two-way highway curves injure over 4,000 people and result in 70 deaths, almost one-fifth of annual roadway fatalities in the state.

Research has shown that dynamic message signs with speed detection components work well in warning drivers to reduce speeds, but these systems require power supplies and cost approximately $14,000 per site. Minnesota’s Otter Tail County alone has over 400 reduced speed curve sites. The Local Road Research Board (LRRB) and MnDOT have been funding research that examines alternative approaches to speed warning systems for drivers approaching curves.

“This smartphone application stitches together existing technologies for GPS, GIS and mapping to provide an inexpensive, cloud-based warning system for drivers,” said Richard West, public works director, Otter Tail County.

In a 2015 study, researchers developed an in-vehicle, vibration-based warning system tested in a driving simulator that relies on data from highway sensors and other sources. Research in 2018 focused on the use of GPS signals to calculate and recalculate a vehicle’s trajectory on roadways to issue warnings. A new phase of this study is refining the approach to draw on vehicle-to-vehicle data.

What Was Our Goal?

The goal of this research was to develop a dynamic curve speed warning system that would employ cloud-based data sharing. The system would not require significant infrastructure investment and would be applicable to all reduced speed curves in the MnDOT highway system.

What Did We Do?

Following a literature search, researchers focused on developing a proof-of-concept smartphone app that would warn drivers of upcoming curves and speed reduction requirements. They also created a database for county road agency managers to input curve locations within their jurisdictions, speed limits and sign facing direction for use with the smartphone app.

Researchers layered the database into their geographic roadway inventory tool, which draws on GPS and mapping data, and combined data from the sources into a cloud-based curve database. Then they developed a geofence system that triggers alerts as the tracking device crosses virtual geographic boundaries.

A smartphone app uses GPS and GIS to trigger a warning via the cloud to smartphone users traveling above the curve speed limit as they pass through a geofence, or virtual geographic boundary, before the curve.

An illustration of the system overview that includes a curved road with geofencing overlays marking two warning areas on the curve, a cloud-based warning database and a smartphone screen showing a “Reduce speed” message.
A smartphone app uses GPS and GIS to trigger a warning via the cloud to smartphone users traveling above the curve speed limit as they pass through a geofence, or virtual geographic boundary, before the curve.

The curve speed warning system was tested on roadways in Otter Tail and Pope counties. After county agencies input curve location and speed limit data into the system, researchers tested the system by running the app while driving a number of highways selected for a high density of reduced speed curves. They adjusted the system based on these field tests to accommodate GPS signal speed, travel speed and cloud data transfer bandwidth.

Researchers then evaluated roadside dynamic speed warning system safety impacts to determine the potential safety and cost benefits from the cloud-based warning system.

What Did We Learn?

The curve speed warning system worked in proof of concept. GPS and cloud data can be drawn on fast enough to provide warnings in time for drivers to respond. Researchers refined geofencing parameters to only pull data for curves within 30 miles of the vehicle to keep data volumes to manageable levels within standard parameters for mobile phone data packages.

“Study results show that this system works accurately. If data from county and state roads were input, the application could be made available to everybody,” said Bradley Wentz, program director, Advanced Traffic Analysis Center, Upper Great Plains Transportation Institute, North Dakota State University.

The core of the system is the curve database, which requires accurate data input by county road agencies. Testing resulted in one performance error, which was traced to incorrect data for the facing direction of a warning sign.

Image of the secondary warning on a smartphone screen showing the message “Slow Down,” the recommended speed of 45 mph and the driver’s current speed of 51 mph in a red circle.
The smartphone app sends a second warning with this message and an audible signal to a driver’s phone.

When vehicles are traveling faster than the speed limit for an upcoming curve, the smartphone app issues a silent, on-screen warning of the approaching curve and speed limit. If the vehicle does not slow its speed sufficiently, the app flashes and issues another warning with an audible signal.

The smartphone app sends a second warning with this message and an audible signal to a driver’s phone.

Safety implications may match crash and speed reductions identified in research on the safety benefits of dynamic sign warning systems. Researchers believe the cost to maintain the software and warning database roughly matches the cost to maintain a traditional dynamic speed warning sign system. But using a single cloud-based system for the entire roadway inventory offers a dramatic cost savings over installing expensive warning sign systems at every curve.

What’s Next?

Researchers have prepared presentations for local audiences and presented findings at the 2018 National Rural ITS Conference. County road agencies can easily update the database, and the system can accommodate not just reduced speed curve locations, but any reduced speed needs, such as seasonal bumps and cracks in pavement, work zones, special events and controlled intersections.

This post pertains to Report 2019-19, “Cloud-Based Dynamic Warning System,” published June 2019. For more information, visit the research project page.

Using Smartphones to Deliver Effective In-Vehicle Work Zone Messages

Under simulated conditions, drivers were not distracted by controlled work zone-related messages delivered through smartphones. In fact, driving performance improved. Researchers also learned that the location of the smartphone did not affect the driver if the message included an auditory component.

“The main goal was to determine whether in-vehicle warnings conveyed through smartphones would be distracting to the driver. We found that wasn’t the case,” said Ken Johnson, Work Zone, Pavement Marking and Traffic Devices Engineer, MnDOT Office of Traffic, Safety and Technology.

“We learned that drivers had a lower mental workload when they experienced the in-vehicle messages. It really didn’t matter what modality we used. Half the messages were auditory only, and half were auditory paired with visual,” said Nichole Morris, Director, University of Minnesota HumanFIRST Laboratory.

What Was the Need?

Highway work zones require drivers to reduce speed and be aware of work crews, lane closures, traffic backups, construction equipment and other potential hazards on the roadway.

Transportation departments have long employed stationary warning signs, sometimes supplemented by portable changeable message signs (PCMSs), to alert drivers to upcoming construction projects. However, some previous studies have indicated that stationary warning signs are not always effective. In addition, PCMSs are costly and may be difficult to deploy in the field.

Smartphone technology offers an opportunity to deliver accurate and early in-vehicle warnings about road construction miles ahead. Digital messages could alert drivers about upcoming work zone conditions and improve safety for drivers and workers in the field.

But receiving in-vehicle messages about work zone conditions could distract drivers from safely operating their vehicles. MnDOT needed to study the advantages and disadvantages of using smart-phones to deliver in-vehicle work zone messages.

What Was Our Goal?

The primary goal of this project was to determine whether smartphones have the potential to safely deliver effective and accurate messages to drivers about upcoming road construction on Minnesota highways.

What Did We Do?

A 7-inch LCD screen
A smartphone was replicated through installation of an LCD screen positioned inside the driving simulator.

The research team developed and conducted an online survey that focused on Minnesota drivers’ perceptions of work zone safety and on their attitudes toward using smartphones and potentially receiving in-vehicle messages regarding work zone conditions.

Data from the surveys was used by the HumanFIRST Laboratory at the University of Minnesota to develop a driving simulation study designed to determine whether in-vehicle messages sent by smartphones could promote safe driving in work zones. The study analyzed 48 drivers operating a driving simulator within two work zones to test reactions to in-vehicle messages as compared to messages displayed on an external PCMS system. Researchers collected data about each participant’s visual attention, driving performance, mental workload and opinions on smartphone technology.

Researchers also reviewed previous national studies and published works to identify environmental and driver behavior risk factors related to work zones.

What Did We Learn?

An analysis of the simulation results showed drivers were very responsive to receiving in-vehicle messages regarding work zones and roadway hazards. Messages presented through smartphones did not cause driver distractions. In fact, some drivers’ performance actually improved following delivery of audiovisual messages.

Drivers preferred to receive audio messages, and researchers learned that a synthesized female voice (like Apple’s Siri) resulted in greater awareness and acceptance from the driver than a more natural or prerecorded voice.

Survey findings showed that only 5 percent of participants use a dashboard mount for their smartphones, while the vast majority keep their phone in the cup holder, on the console, in a backpack or purse, or on the passenger seat. A few participants said they hold their smartphone while driving. Investigating the safety impact of this behavior paired with an in-vehicle messaging system, researchers found that the location of the smartphone within the simulator (on the dash or passenger seat) did not negatively impact driver safety or performance, providing the work zone message contained the auditory component.

In-vehicle messages required less cognitive effort from drivers, and drivers had greater recall of the hazard warning message versus stationary PCMS signage.

A significant number of survey participants, nearly 20 percent, provided unprompted feedback that it was the state’s responsibility to provide factual work zone messaging information and to ensure in-vehicle technology employed does not pose a distraction.

What’s Next?

MnDOT will need to continue research into the viability of smartphones as the way to deliver in-vehicle work zone messages. The simulation study provided the findings needed to advance the project to field testing, where drivers would respond to in-vehicle messages from smartphones on a test track or under real roadway conditions. Another potential topic to explore through further research is the viability of messages delivered through electronic interface or dashboard features offered on some newer vehicles.

MnDOT should identify the medium needed to deliver in-vehicle messages and use the prescribed syntax outlined by the study for communicating messages. Researchers noted the existing 511 service provided by MnDOT currently provides road, traffic, weather and other information. A study should be undertaken to determine whether the 511 or a third-party app would be most appropriate for a future statewide in-vehicle messaging program.


This post pertains to Report 2017-19, “In-Vehicle Work Zone Messages,” published June 2017.

Work-zone warnings could soon be delivered to your smartphone

Imagine that you’re driving to work as usual when your smartphone announces, “Caution, you are approaching an active work zone.” You slow down and soon spot orange barrels and highway workers on the road shoulder. Thanks to a new app being developed by University of Minnesota researchers, this scenario is on its way to becoming reality.

“Drivers often rely on signs along the roadway to be cautious and slow down as they approach a work zone. However, most work-zone crashes are caused by drivers not paying attention,” says Chen-Fu Liao, senior systems engineer at the U’s Minnesota Traffic Observatory. “That’s why we are working to design and test an in-vehicle work-zone alert system that announces additional messages through the driver’s smartphone or the vehicle’s infotainment system.”

As part of the project, sponsored by MnDOT, Liao and his team investigated the use of inexpensive Bluetooth low-energy (BLE) tags to provide in-vehicle warning messages. The BLE tags were programmed to trigger spoken messages in smartphones within range of the tags, which were placed on construction barrels or lampposts ahead of a work zone.

17245-NR20F5

The researchers also developed two applications for the project. First, they designed a smartphone app to trigger the audio-visual messages in vehicle-mounted smartphones entering the range of the BLE work-zone tags. A second app allows work-zone contractors to update messages associated with the BLE tags remotely, in real time, to provide information on current conditions such as workers on site, changes in traffic, or hazards in the environment.

Field tests proved the system works. “We found that while traveling at 70 miles per hour, our app is able to successfully detect a long-range BLE tag placed more than 400 feet away on a traffic barrel on the roadway shoulder,” Liao says. “We also confirmed the system works under a variety of conditions, including heavy traffic and inclement weather.”

“This was a proof of concept that showed that smartphones can receive Bluetooth signals at highway speeds and deliver messages to drivers,” says Ken Johnson, work-zone, pavement marking, and traffic devices engineer at MnDOT. “Future research will look into how we should implement and maintain a driver alert system.”

This future work includes using the results of a human factors study currently under way at the U’s HumanFIRST Laboratory to create recommendations for the in-vehicle message phrasing and structure. Then, researchers plan to conduct a pilot implementation with multiple participants to further evaluate the system’s effectiveness.

According to MnDOT, another phase of the project may investigate how to effectively maintain the BLE tag database. This phase could also investigate implementation options, such as how MnDOT can encourage drivers to download and use the app.

Smartphone app guides blind pedestrians through work zones (updated)

Each year, approximately 17 percent of road construction work zone fatalities nationwide are pedestrians.

At special risk are the visually impaired, who rely on walking and public transportation to get around.

A major challenge  for them is crossing the street — which is even more difficult if an intersection is torn up.

MnDOT has invested significant effort to accommodate pedestrians, particularly those with disabilities, in temporary traffic control situations. This includes requiring temporary curb ramps and alternative routes when a sidewalk is closed.

Researchers, funded by MnDOT, have now developed a cell phone application to guide blind pedestrians around a work-zone.

Illustration of Bluetooth beaconplacement at decision points around a work zone.
Illustration of Bluetooth beacon placement at decision points around a work zone.

Building on previous work to provide geometric and signal timing information to visually impaired pedestrians at signalized intersections, the smartphone-based navigation system alerts users to upcoming work zones and describes how to navigate such intersections safely.

The smartphone application uses GPS and Bluetooth technologies to determine a user’s location. Once a work zone is detected, the smartphone vibrates and announces a corresponding audible message. The user can tap the smartphone to repeat the message, if needed.

The federal government strongly encourages states to provide either audible warnings or tactile maps at work zones where visually impaired pedestrians are expected to be impacted.

“The smartphone application is a step in that direction,” said MnDOT technical liaison Ken Johnson. “It’s a way to see if this type of way-finding device would work.”

Since smartphone use is still limited, the state is also interested in special equipment that could relay the audible warnings at affected work zones.

“However, smartphone use is increasing in the general population, as well as with persons with disabilities, and there will likely be a day when it will be rare to not have a smartphone and this tool could meet road agency needs,” Johnson said.

Before developing the smartphone application, researchers surveyed 10 visually impaired people about their experiences at work zones and what types of information would be helpful in bypass or routing instructions.

The University of Minnesota research team, led by Chen-Fu Liao, tested the smartphone application by attaching four Bluetooth beacons to light posts near a construction site in St. Paul.

Additional research is now needed to conduct experiments with visually impaired users and evaluate system reliability and usefulness.

*Update 4/29/2014: Check out this story from KSTP on the app.

More information

Development of a Navigation System Using Smartphone and Bluetooth Technologies to Help the Visually Impaired Navigate Work Zones Safely — Final Report (PDF, 1 MB, 86 pages)
